I'm aware of consumed time while producing part files with excel driven but I'll save much time when I'll finish my toolbox.
I hope I can explain the mentality behind my own toolbox Same thing exist for bolts washer pins or etc. You may add several size inside part over excel lines and may use multiple sizes over a single part file.Īnd if you plan make good plans for producing additional materials you will be have advantage of this.įor example I produced every bolt file along the y axis and mate my bolts to holes as concentric from origin point of bolt to face of hole and if I need to switch from DIN933 to DIN912 there won't be any misaligned mate or mate error.
#Solidworks toolbox. making bolts longer archive
When choosing the option 'Download Only' in the Installation Manager, it would be nice if there were an option to choose the components you wanted to download specifically, like SOLIDWORKS PDM Archive and. It’s a DIN933 bolt linked with an excel file. SOLIDWORKS Toolbox API Help (1) The electrical scheme (1) Training (1) User Interface (1) eDrawings API Help (1) eDrawings Installation (1) Suggested Additional Installation Manager Options. You'll understand me if you have a look at the file I'd uploaded for you. Instead of doing I'm started to building up a library that consist of part files which are produced by me then configured with an excel file. SOLIDWORKS does provides an application to allow the part to be toggled between being a Toolbox part and just a SOLIDWORKS part. Even with Save As it still has references as a Toolbox part. I understand your point and may suggest you same thing what I'm doing.Īctually I don't want to use SW Toolbox anymore because It's hard to browse and navigate It needs sw premium, when i send a design to someone he can’t see toolbox file or see biggest sizes of toolbox files or some other issues that we always discuss in forums, so I quit using SW toolbox. The Toolbox part can be opened and Save As (to your own file location).
